GEPRC Team Really Excitedly to release the GEPRC CineLog25 CineWhoop drone. All innovations are disruptive for GEPRC CineLog25.
CineLog25 will be available in three versions: CineLog25 HD PRO, CineLog25 HD Micro, and CineLog25 Analog.
The most noteworthy feature of CineLog25 is the lightweight quadcopter that can shoot video by GoPro Lite. It adopts the most popular backward push design on the FPV field at present. It can effectively use the thrust-weight ratio of the propeller to obtain higher flight efficiency. In the overall layout of the drone, we put VISTA HD in the center of the quadcopter, so that the center of gravity of the quadcopter is in the middle, The propeller Inlet is smoother and the noise is lower. Redesigned the shock absorption structure of the camera mount and GoPro Lite, Eliminated the jelly of the camera and FPV camera, and we can use 3, 4, and 5 damping rings according to the flight state to obtain the best stability in vibration and noise.
The F411-20A F4 AIO and GEPRC NEW 1404 4500KV motors are used in flight systems and power systems.
The power battery can be compatible with 450mah ~ 750mah.
The flight time of CineLog25 is around 5.5 minutes (it depends on your flying habits). The stable electronic equipment and advanced frame materials make the quadcopter stable and can achieve all FPV freestyle tricks easily. The customized EVA protective foam cushioning around the frame is more elastic and can effectively protect the fuselage when a crash happens!
The CineLog25 is assembled and debugged by GEPRC Team. It has a smooth flight experience and excellent performance. It has every attribute you could want.
1. New camera damping system
The New camera damping system eliminates the video’s jelly and FPV camera’s vibration in terms of design, The damping construction can be adjusted the harder or softer to suit the Flight State. There are Three, Four, and Five damping rings that can be used to provide sufficient stability in vibration and noise.
2. Brand-new exclusive pusher frame
The CineLog Whoop Quadcopter adopts a brand-new stunning pusher frame design, Including an ultra-light carbon plate and new material, strength increases by 20%, and efficiency increases by 15%
3. Low noise optimization
Cinelog Whoop Quadcopter Increases the Air Inlet volume and it with the EVA foam cushioning, Reduces the Airflow Resistance to create extremely low flight noise and greater reduction of noise from external vibrations
4. Long-range flight
High-efficiency power matching, The latest GEP 1404 motor power output scheme, and Brilliant Tune have further Improved the flight time
5. Low center of gravity design
The CADDX VISTA was placed at the bottom, Optimized Design for the Air Inlet Structure. It’s point of the best importance is a low center of gravity “pusher-style” inverted frame, increased efficiency of at least 15%
6. Perfectly Compatible with most mainstream cameras
Compatible with SMO 4K, Gopro6 lite and Gopro8 Lite (coming soon),etc…
7. Adjustable lens angle
The flight angle of 0-40 degrees can be adjusted according to the flight requirements,
The camera’s angle can be adjusted to meet your variety of Shooting needs
8. With EVA foam cushioning
Integrated EVA design, the overall shape looks more coordinated,
9. Optimized bottom design.
The bottom part increases the strength of the landing and perfectly protects all electronic equipment
10. Camera power line output
With its power cable output to the camera (Gopro6 & Gopro8),
It has its own Video Recording Wire, The camera can be turned off or on directly Via a Remote controller
Item Name: CineLog 25 Quadcopter Analog Version
Flight Controller： GEP-20A-F4
OSD：BetaFlight OSD w/ AT7456E chip
ESC： BLheli_S 20A
VTX：5.8G 600mW VTX
Camera: Runcam Nano2
Props: GEMFAN D63-3
Motors： GR1404 4500KV (Upgraded Version)
CineLog25 Analog Weight: 111.1g (Without battery)
Battery: Recommend 4S 450-750mAh Lipo with XT30 plug (Not Included)
1x CineLog Quadcopter Analog Version
4x D63-3 Props(Pair)
1x GOPRO Lite 3D TPU Seat
2x EVA Pad
2x Battery non-slip mat
2x Battery strap
